Intermatic FD36H 6 Hour 125-277V SPDT Decorator Series Spring Wound Timer, Ivory
$71.95 Original price was: $71.95.$50.37Current price is: $50.37.
SKU: Intermatic WBB200426 Categories: Spring Wound Timers, Switches, Receptacles & Sensors, Timers & Dimmers Tags: 1 @ 125V, 2 @ 250 V, 125-277 V, 20 A, 7 Amp 125 VAC W, FD36H, Intermatic, Lighting & Electrical, White
- Quick responses, top-notch service.
- Get the Best for Less
- Secure Payments, Secure Shopping
- fast shipping

These energy saving timers use no electricity to operate. These timers are designed to replace any standard wall switch, single or multi-gang, and automatically limit the “ON” time of fans, lights, motors, heaters and other energy consuming loads. Time limits of 5, 15, 30 and 60 minutes and 2, 4, 6 and 12 hours are available. The “hold feature” allows the user to override the automatic shut-off function for extended use of the load as required. Supplied with a molded white, ivory or almond time dial plate designed to fit either toggle or decorator style switch plates; single or multi-gang with no field modifications required to fit either style switch plate. Time saving “up front” terminal connection with teeter type terminals and an easy “press-on” knob design ensure quick and easy installation. Fits standard 2 – 1/2 inch deep junction box. Resistive Wattage is 20 Amp 125 VAC 50/60 Hz; 10 Amp 250 VAC 50/60 Hz; 10 amp 277 VAC 50/60 Hz; Tungsten Wattage is 7 Amp 125 VAC. Product features 1 @ 125V, 2 @ 250 V motor.
| Height | Fits Standard 2 – 1/2 inch deep Junction Box in |
|---|---|
| Tungsten Wattage | 7 Amp 125 VAC W |
| Horsepower | 1 @ 125V, 2 @ 250 V |
| Voltage | 125-277 V |
| Color Family | White |
| Amperage | 20 A |
| Manufacturers Part Number | FD36H |
| Key | 147129 |
| Switch Type | SPDT |
| Time Cycle | 6 Hrs |
| Brand | Intermatic |
